KIPP - Bedienteile | Normelemente K0006.2511108X40 Handle, Stainless Steel Thread, Position of The Eccentric Lever, variably Adjustable, 2 Pieces Made, Aluminium Black, M8X40
Product details
| Management number | 221119383 | Release Date | 2026/05/03 | List Price | US$18.06 | Model Number | 221119383 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Tilting eccentric levers are used when the position of the clamping lever relative to the clamping axis only allows a certain position. The fine thread on the pin screw adjusts the exact position of the clamping lever with the help of a screwdriver. In machine and tool construction, components can be quickly and flexibly mounted on aluminium profile systems and flat workpieces clamped. In this way, a quick and easy clamping process is ensured without additional tools and tools. The torque-free clamping is also of great advantage, as the element to be fixed does not have to be secured against twisting. In addition, the eccentric lever can always find the right clamping force, so that damage to the workpiece is excluded. Very often, eccentric levers, also known as quick release, are used when adjusting the saddle on bicycles. The eccentric lever is also indispensable from the rehabilitation and medical sector, where sitting or lying positions are often changed
- With adjustable eccentric levers from KIPP, you can fix and open objects quickly and easily: screw in bolts, press the lever down, done! Position of the eccentric lever can be individually adjusted using a slotted screwdriver.
- Application: DIY area (cross-cut saws, standing drills, aluminium profiles, etc.), hobby (bicycle, scooter, photo/camera tripods, etc.), commercial (stage technology for adjusting headlights and speakers, clamping technology for clamping workpieces, etc.)
- Advantage: quick opening and closing of the eccentric lever, handle position of the eccentric lever can be freely selected by the fine adjustment of the bolt, clamping force can be varied, suitable for all common threads
- Product details: dimensions (L x W x H): 108 x 33.3 x 68.5 mm; weight: 120 g; eccentric lever aluminium adjustable; colour: black; external thread stainless steel
- Box contents: 1 adjustable eccentric lever M8X40
| Color | Aluminium Black |
|---|---|
| Shape | Oval |
| Brand Name | Kipp |
| Metal Type | Alloy Steel, Aluminum, Stainless Steel |
| Style Name | External thread stainless steel |
| Unit Count | 1.0 Count |
| Handle Type | Lever |
| Item Weight | 0.12 Kilograms |
| Finish Types | Brushed |
| Manufacturer | KIPP |
| Model Number | K0006.2511108X40 |
| Material Type | Aluminum |
| Item Type Name | Adjustable eccentric lever made of stainless steel |
| Exterior Finish | Stainless Steel |
| Handle Material | Stainless Steel |
| Number of Items | 35 |
| Hand Orientation | Ambidextrous |
| Additional Features | Adjustable |
| Included Components | Eccentric lever |
| Projection Distance | 68.5 Millimeters |
| Item Dimensions L x W | 4.31"L x 2.7"W |
| Manufacturer Part Number | K0006.2511108X40 |
| Specific Uses For Product | Stage technology, clamping technology |
| Global Trade Identification Number | 04059245209798 |
